Angled Blade Plate 130

With 4 DCP dynamic compression holes and slot for tension device. (from 6 holes up)

These  plates have an angle 130 between blade and shaft.

Fixation with Cortex Screw 4.5mm.

For femoral neck and pertrochanteric fractures.

Profile
Thickness : 5.6 mm
Width : 16.0 mm
Hole Spacing : 12.0 mm (4 holes)
Hole Spacing : 16.0 mm (6-12 holes)
U-Profile Blade : 6.5 x 16.0 mm
